Produce your CTP plates in HD quality.
CTP system capable of imaging flexo and letterpress plates, including steel-back plates, at 4000 DPI with no additional costs for options. It also images plate scraps at maximum speed.
A “turnkey” solution for printers who want to become self-sufficient and produce high-resolution digital plates in-house.
Available in the following formats: 330×430 mm, 430×680 mm, and 635×762 mm, and capable of producing plates up to 2.84 mm thick.
Every model also allows the imaging of films for screen printing frames and for the possible creation of analog plates.
Choose your CTP version.
What do you want to produce?
You can image any flexo plate, solvent-based or water-based, at 4000 DPI.
You can produce letterpress plates with either film base or steel base.
The CTP allows you to produce high-quality outputs, also ideal for screen printing frames.
Form
Ask for. more details
Fill out the form and find out which CTP is ideal for your production.
SPECIAL CONTENTS
Watch the video!
We prepared some special videos which shows you plate production from file creation up to the ctp machine. We will put the plate into the ctp machine and you will see final result.
These videos will help you to understand how important and easy is to use a ctp machine to optimize your production
CTP SYSTEM
Discover the advantages in production
HD QUALITY
Always image at maximum quality to produce high-resolution plates.
Compact sizes
No need to produce full plates. With us, you can also image smaller formats at maximum speed.
Steel-back plates as well.
Produce steel-back plates without the need for expensive add-ons.
Fast positioning
“Curve-and-lock” loading system, with no need to manually secure the plate to the drum.
Automatic balancing
The drum is automatically balanced according to the size and thickness of the loaded plate, always maintaining maximum writing speed.
Automatic selector
Each laser imaging is performed at the optimal focal distance to ensure consistently sharp and clear screens.
In case of a laser diode failure, the automatic light path selector technology automatically uses the maximum number of remaining channels, adjusting them to ensure normal operational continuity with minimal reduction in nominal productivity.
Total control over results.
An intuitive software that allows you to calibrate your plates with ease.
No mandatory service contracts.
No system lockouts, no mandatory service contracts, no need for costly technical interventions from the manufacturer.
Easy Maintenance
Simple and fast maintenance system that doesn’t require costly interventions from external technicians.
How to use the machine
It's very easy !
1
Place the plate
Place the plate on the drum, and the convenient clamp system will automatically secure it.
2
Select your file.
An intuitive software allows you to select the file and settings you want, and create your digital plate with ease.
3
Ready for exposure.
After a few minutes, the imaged plates will be ready for exposure.
OPTIONS
Which are the available options?
CTP systems can be customized to match your production needs.
Speed
For high-volume production, you can choose the 32-channel version, which allows you to double the production speed.
Format
Based on the most commonly used formats, you can choose the size that best suits your needs.
Form
Ask for. more details
Fill out the form and find out which CTP is ideal for your production.
FREE REPORT
Films are disappearing.
A comprehensive report dedicated to production managers frustrated by the high costs of films and the upkeep of outdated image-setters—constantly battling machine downtime and material waste.
Our satisfied customers
Our skills At your service
PEPI SG
flexo labels
“Most CTP systems have fixed formats, so producing smaller plates can be very cumbersome. With this one, however, you can load any plate size, and the machine will still image it at maximum speed.”
Tosi
food packaging labels
“It was a great investment. Even more importantly, we felt truly supported. As a company that didn’t handle internal development, we needed step-by-step guidance—and we were very satisfied with the support you provided.”
You ask, we answer
F.A.Q.
Are Special Requirements Needed for the CTP?
Absolutely not, just a power connection and compressed air, and you’re ready to use the CTP.
I use different types of plates — could that be a problem?
Absolutely not — our CTP images any type of plate: steel-back or film-based letterpress, water- or solvent-based flexo, and it’s also ideal for producing films for screen printing frames.
More details
